Brief Introduction on PEW Series Jaw Crusher

The PEW series jaw crusher is a single toggle jaw rusher, characterized by attention to detail, in both design and manufacture. The frame consists of two side plates of rolled steel, plus hollow castings at front frame end and moving jaw which give a high rigidity/weight ratio. Largeradius transition areas reduce stress concentrations and welds are positioned in low-stress areas. The advantage of a welded frame is that it is equally strong in all directions and ensures excellent

durability against shock-loads. Thus minimizing the risk of failure on the main-frame, as with a bolted construction.

Utilization of Jaw Crusher

All our jaw crushers are of the single toggle type, with a deep, symme-trical crushing chamber and easy setting adjustment. Each model has a large feed ope-ning for its size and an ideal nip angle, giving smooth material flow, high reduction efficiency and high capacity.

Features

Robust with low weight.

Inc reased uptime thank s to operator friendly design.

Uniform welded construction.

High capacity and high reduction.

Effective, active feed opening.

Jaw plates for all types of applications.

Specification
